We offer CAD models for almost all MÄDLER® products for direct use in your design planning.
You can choose between the following 2 options:



1) Download from our product pages for 3D CAD models in STEP format - quickly and easily



Free of charge without registration. Just click the button "CAD" in the row of the article,
then a ZIP-file will open.





2) PART2CAD: Insert CAD models directly into your CAD software



With PART2CAD as an add-on for our MÄDLER eCATALOG at PARTcommunity, you can generate
and transfer several formats in 3D and 2D directly into your CAD system*:
http://maedler.partcommunity.com/3d-cad-models/

This service is currently available for the following CAD systems:

* Please note: PARTcommunity requires a registration in advance (free of charge) as well as the plug-in
installation of PART2CAD. Registration with your access data to the MÄDLER® webshop is not possible.



Alternatively, we can send you our CAD data for free on DVD. Please direct your order to info@maedler.de
